The Saunacore Steam Vaporizer model is unique in design and performance. Its engineered design of chic meets durability is what makes this model above the rest. A water reservoir for the ability to manually pour water into the tank to allows for approx. 40-50% more humidity.
Sizing & Selection
Measure the length, width and height (in feet) of the
sauna. Multiply the three measurements together to get
the basic room volume in cubic feet.
Sauna room suggested height to be maximum 7ft.
L x W x H = CUBIC FEET
Divide the CUBIC FOOTAGE BY 50
= Kilowatts Required
(Select the next size of Saunacore model stove which
exceeds the calculated room cubic feet.)
7ft length, 5 ft wide, 7 ft high (7 x 5 x 7 = 245)
245 divided by 50 = 4.9 KW
A 5 KW (5000 WATT) is required.
If there is any doubt in size, always recommend the next
larger size. (This is a general guideline.)
- Entire body stainless steel
- Energy efficient
- Wall mount -corner or flat wall
- Heat deflector and vented body design
- Heavy duty grade
- Ltd lifetime warranty
- Mercuri digital control INCLUDED
- Steam vaporizer tank
- Sauna stones included
- 4000watts 240v 1p 16.7amps
- Special voltage upgrade available upon request
- 38.1cm x 25cm x 60cm
